Cobolt 08-01 Series

Compact narrow linewidth lasers

The Cobolt 08-01 Series is a family of compact narrow linewidth continuous-wave lasers, including high performance single frequency diode pumped lasers (DPL) as well as frequency stabilized diode lasers (NLD). This Series offers the broadest wavelength range and highest performance lasers on the market for Raman spectroscopy.

405 nm – 1064 nm, up to 500 mW
Excellent wavelength stability, < 1 pm (over ±3 °C, 8 hrs)
Guaranteed excellent spectral purity, > 80 dB
Integrated electronics
Integrated optional optical isolator and spectral clean-up filter
Fiber coupled option
Ultra-robust, proven reliability
Ensured stable narrow linewidth emission over the full laser lifetime and a wide range of operating conditions
24 months warranty, unlimited hours

Applications

Perfect for Raman spectroscopy, interferometry, dynamic light scattering.

Specifications

Product	Wavelength	Power	Bandwidth
Cobolt 08-NLD	405 nm	30 mW 40 mW	< 1 pm
Cobolt 08-DPL	457 nm	25 mW 30 mW	< 1 MHz
Cobolt 08-DPL	473 nm	25 mW 40 mW 50 mW	< 1 MHz
Cobolt 08-NLD	488 nm	40 mW	< 1 pm
Cobolt 08-DPL	515 nm	25 mW 50 mW	< 1 MHz
Cobolt 08-DPL	532 nm	25 mW 50 mW 100 mW 200 mW 400 mW NEW!	< 1 MHz
Cobolt 08-DPL	561 nm	25 mW 50 mW 100 mW 200 mW NEW!	< 1 MHz
Cobolt 08-NLD	633 nm	30 mW	< 1 pm
Cobolt 08-NLD	638 nm	80 mW	< 1 pm
Cobolt 08-DPL	660 nm	50 mW 100 mW NEW!	< 1 MHz
Cobolt 08-NLD	785 nm	120 mW	< 1 pm
Cobolt 08-NLDM	785 nm	500 mW	< 70 pm
Cobolt 08-NLDM-ESP	785 nm	400 mW	< 70 pm
Cobolt 08-NLD	830 nm NEW!	100 mW	< 1 pm
Cobolt 08-DPL	1064 nm	400 mW	< 1 MHz

Performance Data (click to enlarge)

Data sheets

Cobolt 08-01 Series:
Narrow Linewidth Lasers

Manuals

Cobolt 08-01 Series:
Narrow Linewidth Lasers

Literature (see also application specific pages)

Title	Application	Publication
Editorial Low frequency Raman Spectroscopy Physics Best 2020	Low frequency Raman spectroscopy	Physics Best Wiley April 2020
Low frequency Raman Spectroscopy	Low frequency Raman spectroscopy	Application note
Editorial How to choose a laser for Raman spectroscopy	Raman spectroscopy	Laser Focus World Aug 2018
Lasers for Raman using 405 nm narrow linewidth	Raman spectroscopy	Application note
Lasers for Raman using 785 nm	Raman spectroscopy	Application note

Software

Software	Description
Cobolt Monitor	Cobolt Monitor^TM is a combined GUI for all Cobolt laser models. The GUI supports simultaneous connection and monitoring of multiple lasers, configured for either RS232 or USB2.0. The GUI automatically searches for new Cobolt lasers connected to the computer and presents them listed.
USB Driver	To connect to the laser via USB, the USB driver must be installed. When installed, a virtual COM port will be created to communicate with the laser.
Lab View	Use to integrate the Cobolt lasers into Lab view environment.
